Product Information

Application Scope

SANDAO New Material's ms adhesive can be used in many industries.SANDAO New Material always provides customers with reasonable and efficient one-stop solutions based on the professional attitude.

Company Advantages
1. SANDAO what is rtv silicone is manufactured according to applicable international standards.
2. The product has passed multiple quality standard tests.
3. The product is stable in performance and long in service life.
4. This product is worldwide renowned for its huge economic results.

our product

SD9099 Solar module Sealant

SD9099 Solar module Sealant is a one component room temperature curing silicone adhesive that does not corrode metals and plastics.

Application

The solar component sealant is used for sealing the solar cell module frame, bonding the solar cell module junction box, and sealing the solar lamp. The solar sealant has excellent UV resistance, yellowing resistance, excellent weathering resistance, rain, anti-fouling and hail impact resistance, and good adhesion to aluminum, glass, junction box plastic and other materials.

Plastic junction box bonding

Seal of solar cell frame

Solar light fixture

Glass bonding

Bonding of solar cell junction box

Aluminum bonding

product Performance

Type	SD9099
Color	White paste
Density(g/cm3)	1.35～1.40
Surface dry（25℃,min）	≤12
Tensile strength （MPa）	≥2.0
Elongation（%）	200～300
Shear strength（MPa）	≥2.0
Hardness(shore A)	50~55
Temperature range（℃）	-50～250
Permittivity（@60Hz）	2.8
Dielectric intesity（kV/mm）	≥18
Volume Resistance（Ω.cm）	1×1015
Flammable	UL 94-V0

Product details

SD9099 solar component sealant

SD9099 solar component sealant is a one component room temperature curing silicone adhesive.

White paste

Excellent UV resistance, yellowing resistance, excellent weathering resistance.

Green environmental protection

It is harmless to the human body, SGS environmental protection certification, and the flame retardant performance reaches UL 94 V-0.

Long storage period

Stored in a cool dry place with a shelf life of one year, packaging size 310ML / PCS

Use instructions

The surface of the substrate must be degreased and dried, and corona treatment can improve the bonding effect. The silicone adhesive sealant has a surface cure time of about 20 minutes and is fully cured after 24 hours.

Notes：

1. Keep thermal paste out of reach of children.
2. Manufacturer shall not be liable to the buyer or any third party for injury, loss or damage directly or indirectly resulting from the use of, or inability to use, the product. Recommendations or statements other than those contained in a written agreement signed by an officer of the manufacturer shall not be binding by the manufacturer. This product has not been tested for, and is therefore not recommended for, uses for which prolonged contact with mucous membranes, abraded skin, or blood is intended; or for uses which implantation within the human body is intended.

Company Features
1. Huizhou SANDAO New Material Co., Ltd is very adept at manufacturing and supplying prime One-component RTV silicone rubber TDS for customers and users.
2. Huizhou SANDAO New Material Co., Ltd has strong technical strength and advanced manufacturing technologies.
3. We have repeatedly analyzed the market demand for rtv silicone rubber . Welcome to visit our factory! SANDAO always put our customers the first. Welcome to visit our factory! All employees work for SANDAO New Material will make unremitting efforts to bravely climb the peak of the industry. Welcome to visit our factory! With ambition, SANDAO will continue to develop One-component RTV silicone rubber TDS industry. Welcome to visit our factory!
