SANDAO New Material is certified by various qualifications. We have advanced production technology and great production capability. silicone rubber has many advantages such as reasonable structure, excellent performance, good quality, and affordable price.Compared with other same kind of products, silicone rubber produced by SANDAO New Material has the following advantages and features.
Application Scope
silicone adhesive produced by SANDAO New Material is mostly used in the following aspects.SANDAO New Material always provides customers with reasonable and efficient one-stop solutions based on the professional attitude.
Company Advantages 1. Much advanced quality inspection equipment is used in SANDAO epoxy adhesive production. It is finely handled by the coordinate measuring machine (CMM), caliper, microcaliper, gauge, and pass meter. 2. Product security can be provided through this product. It can make items tamper-resistant, can help reduce theft and prevent harm from dangerous items. 3. This product is a good way to display products in retail. It is a sure way of bringing an exhibition to life. 4. The product will enable one to boost the aesthetics of his space, creating a more professional environment for any event.
our product
bg
Epoxy resin AB adhesive SD811
Epoxy resin AB adhesive SD811 is a two-component high-temperature resistant adhesive based on epoxy resin. It has high strength, weak acid-base resistance, impact resistance, low smell, resistance to most chemical media, extreme temperature and excellent electrical insulation characteristics. Mainly suitable for high temperature resistant metal, ceramic, etc.
Feature
◪ Fast curing, wide range of application, high bonding strength, water resistance, oil resistance, fatigue resistance.
◪ Excellent resistance to high and low temperature, can work in the temperature range of 60-150 ℃.
Application
bg
Sandao Epoxy resin AB adhesive are used for bonding of metal, ceramic, glass, electroplating / paint / magnetic materials, such as aircraft motor, automobile, machinery, ship, electronics, electrical apparatus, instrument, building, furniture, toys,. high temperature resistant parts such as railway vehicles ,etc, AB glue can also be used to adhesive water tank, oil road, carburetor, cylinder cover, exhaust pipe, bushing of driving shaft, plastic parts such as baffle, vehicles lamp glass, car handle, etc.
Electroplating paint bonding
Furniture bonding
Glass bonding
Motor component bonding
Ceramic bonding
Mechanical component bonding
product Performance
bg
Epoxy resin AB glue
SD811 part A
SD811 part B
Appearance /color
transparent
transparent
Viscosity (mPa.s 25℃)
8000-12000
10000-13000
Specific gravity (g/ml 25℃)
1.0-1.05
1.0-1.05
Ratio(weight ratio pbw)
1
1
Gel time under normal temperature(25℃)20g
45-60mins
Curing time
80℃
30mins
Temperature range(℃)
-60℃-150℃
Hardness(shore-D)
70/75
Epoxide equivalent(g/eq)
185/190
/
Active hydrogen equivalentg/eq
/
185/195
Distortion temperature HDT
80℃
Solume resistivity(Ω.cm)25℃
1.0~1015
Surface resistivity(Ω.cm)25℃
0.9×1015
Shear strength of different materials(Mpa)
Aluminum / copper
16-19
Steel
17/20
ABS
7-8
Product details
bg
Transparent epoxy resin AB glue
SD811 Epoxy AB Adhesive is an epoxy resin two component high Temperature adhesive.
Transparent liquid
Fast curing speed, wide application range, extreme temperature and excellent electrical insulation characteristics.
Green environmental protection
odorless, non-pollution, high strength, weak acid and alkali resistance, impact resistance, high adhesion strength, water resistance, oil resistance, fatigue resistance.
AB mixing tube
packaging specifications: 64g / tube.
Use instructions
bg
Put on AB glue gun and put on the thread mixing head.
The thickness of adhesive layer should be 0.05mm, the coated object should be clamped immediately, and the maximum bonding strength will be guaranteed by uniform contact pressure.
To obtain the highest mechanical strength, the surface of the material can be polished or sandblasted, and then the dust and oil stains on the surface can be scrubbed with a special solvent.
Adhesive should be put on both sides of the object and fix the splice in avoid of dislocation. Do not mix the lid of A and B to prevent contamination of the adhesive.
Caution
1. Epoxy resin AB glue is slightly irritating, please wear gas mask and anticorrosion gloves when operating.
2. Cover at any time after each extraction, lest moisture absorption affect curing and performance.
3. Mass use of this product needs to be in a well-ventilated place.
Packaging and preservation
bg
Epoxy resin AB sealant is packed with AB mixed pipe, 64g/ pcs, transported as non-dangerous goods, should be stored in a dry, shady place (below 5 ℃ ~ 26 ℃), the shelf life is within 12 months from the date of manufacture.
Company Features 1. SANDAO has been centering on producing high quality epoxy adhesive . 2. SANDAO launched a high-quality epoxy resin that successfully broke the deadlock of lack of innovation and homogeneous competition. 3. Our ultimate goal is to become an international Two-component epoxy structure bonding supplier. Get price! SANDAO will develop horizontally to meet the needs of the foreign trade market. Get price! Huizhou SANDAO New Material Co., Ltd will ensure increased customer satisfaction during the shopping process. Get price!
Packaging & Shipping
Features
product name:
Araldite 2015 Ab 2kg
packing:
2kg/set
product manual:
Ai Da Da 2015 Epoxy resin is a two-component, room temperature curing, flexible adhesive paste adhesive. Love up to 2015 with thixotropy, hanging thickness of up to 10mm. Lovely 2015 is particularly suitable for bonding SMC and GRP.
colour:
2015AIs gray 2015B Is gray
deal with:
The strength and durability of the bond depends on the appropriate adhesive surface.
The adhesive surface should be cleaned with at least oil-based cleaning agents such as acetone or isopropyl alcohol (to plastic) to remove all grease, dirt and dust. Can not use low alcohol, gasoline or paint thinner. By mechanical grinding or chemical corrosion (pickling) has been cleaned the surface, you can get the highest strength, the best durability of the adhesive, polished should be a second cleaning process.
Features:
1,Tough adhesive 2,Applicable to SMC and GRP bonding 3,Low shrinkage 4,Fill the gap, sagging thickness of up to 10mm 5,High shear, peel strength, peel strength
Curing time:
At room temperature at 23 degrees Celsius, the curing time is 24 hours
