SANDAO inexpensive epoxy resin glue resistant for electronic products

SANDAO inexpensive epoxy resin glue resistant for electronic products

SANDAO inexpensive epoxy resin glue resistant for electronic products

Model number
SD805
MOQ
1pcs
Color
transparent
Package
64g/pcs 2kg/pcs
Main characteristic
tack free time is 5mins
Main application
etc
Lead time
within a week after payment
Price
Get Latest Price
Get the latest price
Quantity Needed:
Pieces
E-mail:
Application Scope
SANDAO New Material's ms adhesive can be widely used in various fields.SANDAO New Material has been engaged in the production of silicone rubber for many years and has accumulated rich industry experience. We have the ability to provide comprehensive and quality solutions according to actual situations and needs of different customers.
Enterprise Strength
  • SANDAO New Material attaches great importance to the impact of service on corporate reputation. We are dedicated to providing professional and high-quality services for customers.
Company Advantages
1. The quality of SANDAO epoxy resin glue is ensured. It has passed strict quality tests and visual inspections by both the authority and our appointed agent.
2. epoxy resin with the advantage of epoxy resin glue is widely applied.
3. The product is really economical in price and has a bright market prospect.
4. We have the widest range of production technologies for achieving these great performances and quality.

our product

bg


Sandao epoxy resin AB adhesive SD805
Sandao epoxy resin AB adhesive SD805 is a two-component high-temperature resistant adhesive based on epoxy resin. It has the advantages of fast drying, high strength, weak acid and alkali resistance, impact resistance, low smell, resistance to most chemical media, extreme temperature and excellent electrical insulation. Mainly suitable for high temperature resistant metal, ceramic, etc.

Feature

  • ◪   Fast curing, high viscosity, high strength, impact resistance, high insulation, transparent, low smell, no corrosion.

  • ◪   Epoxy resin AB sealant can resist most chemicals and solvents.

  • ◪   Temperature-resistant -40-120 ℃.

Application

bg


Sandao fast drying Epoxy resin AB sealant are used for bonding of metal, ceramic, glass, electroplating / paint / magnetic materials, such as aircraft motor, automobile, machinery, ship, electronics, electrical apparatus, instrument, building, furniture, toys,. high temperature resistant parts such as railway vehicles ,etc, AB glue can also be used to adhesive water tank, oil road, carburetor, cylinder cover, exhaust pipe, bushing of driving shaft, plastic parts such as baffle, vehicles lamp glass, car handle, etc.

Glass bonding

Electroplating paint bonding

Ceramic bonding


Motor component bonding

Mechanical component bonding

Furniture bonding



product Performance

bg


Epoxy resin AB glueSD805 part ASD805 part B
Appearance /colortransparenttransparent
Viscosity (mPa.s 25℃)8000-1500011000-18000
Specific gravity (g/ml 25℃)1.0-1.051.0-1.05
Ratio(weight ratio pbw)11
Gel time under normal temperature(25℃)20g5mins
Curing condition//
Temperature range(℃)-40℃-120℃
Hardness(Shore-D)73/80
Epoxide equivalent(g/eq)185/190/
Active hydrogen equivalent g/eq/185/195
Distortion temperature HDT80℃
Volume resistivity(Ω.cm)25℃5.0×1016
Surface resistivity(Ω.cm)25℃7.5×1012

Shear strength of different materials(Mpa)

Aluminum / copper15-18
Steel16/19
ABS6-7

Product details

bg
Quick-drying transparent epoxy resin AB glue
SD805 epoxy resin AB adhesive is a two-component high temperature adhesive based on epoxy resin, which is suitable for high temperature ceramic metal bonding.
Transparent liquid
Fully transparent and trace-free, epoxy resin is resistant to most chemicals and solvents and is resistant to temperatures from -40 to 120 °C.
Green environmental protection
odorless, non-corrosion, non-pollution, fast curing, high viscosity, high strength, impact resistance, extreme temperature and excellent electrical insulativity properties.
AB mixing tube
packaging specifications:64g / tube.

Use instructions

bg


  • Put on AB glue gun and put on the thread mixing head. The thickness of adhesive layer should be 0.05mm, the coated object should be clamped immediately, and the maximum bonding strength will be guaranteed by uniform contact pressure.

  • To obtain the highest mechanical strength, the surface of the material can be polished or sandblasted, and then the dust and oil stains on the surface can be scrubbed with a special solvent.

  • Adhesive should be put on both sides of the object and fix the splice in avoid of dislocation.

  • Do not mix the lid of A and B to prevent contamination of the adhesive.

Caution

  • 1.   AB adhesive is slightly irritating, please wear gas mask and anticorrosion gloves when operating.

  • 2.   Cover at any time after each extraction, lest moisture absorption affect curing and performance.

  • 3.   Mass use of this product needs to be in a well-ventilated place.


Packaging and preservation

bg


Epoxy resin AB adhesive is packed with AB mixed pipe, 64g/ pcs, transported as non-dangerous goods, should be stored in a dry, shady place (below 5 ℃ ~ 26 ℃), the shelf life is within 12 months from the date of manufacture.
