epoxy resin bonding for screws SANDAO

epoxy resin bonding for screws SANDAO
  • epoxy resin bonding for screws SANDAO
  • epoxy resin bonding for screws SANDAO
  • epoxy resin bonding for screws SANDAO
  • epoxy resin bonding for screws SANDAO
  • epoxy resin bonding for screws SANDAO
  • epoxy resin bonding for screws SANDAO
  • epoxy resin bonding for screws SANDAO
  • epoxy resin bonding for screws SANDAO

epoxy resin bonding for screws SANDAO

Model number
SD823
MOQ
1pcs
Color
Blue
Package
64g/ set
Main characteristic
curing time is 5mins. Ratio is 10:1
Main application
metal, hard plastics, composite materials, glass, etc.
Lead time
within a week after payment
Price
Get Latest Price
Get the latest price
Quantity Needed:
Pieces
E-mail:
Enterprise Strength
  • SANDAO New Material constructs a scientific management system and a complete service system. We strive to provide customers with personalized and high-quality services and solutions to meet their different needs.
Company Advantages
1. SANDAO resin glue adopts cutting edge chips that combine highly efficient materials and optical design. The chips deliver superior value for the product.
2. The product will not have the yellowing problem. The surface is treated with high-temperature paint up to 200 degrees which makes the color stick and fast.
3. Mature sales network will not only contribute to the sales of epoxy resin but also help SANDAO develop more partners.

our product

bg


Epoxy resin structural adhesive SD823
Epoxy resin structural adhesive SD823 is a kind of high strength acrylate structural adhesive, two-component 10:1, medium viscosity, fast curing (25 ℃, 5min), fast bonding and fixing, hard and toughness after curing, high adhesion strength and impact resistance. Anti-aging, good solvent resistance.

Feature

  • ◪   High strength, high performance, elastic, instantaneous, two components, safety and environmental protection

Application

bg


suitable for fast fastening and bonding of metal, hard plastics, composite materials, glass, etc., especially for mobile phone and notebook shell, screen and keyboard frame, suitable for high speed production line in electronic factory.

Glass bonding

Hard plastic bonding

Phone case bonding


Composite bonding

Metal bonding

Notebook case bonding



product Performance

bg


1.Before curing
performanceComponent AComponent B
colorwhiteblue
specific gravity(25℃)1.051.14
Viscosity (25℃ m pa. s )85000-10000035000-50000
2.mixed characteristic
colorBlue
ratioA:B=10:1
Applicable time (mins)4
3.After Curing characteristic
shear strength(N/mm.2)PC/Aluminum magnesium10.02
shear strength(N/mm.2)PC/PC6.71
Split / elongation % 150
Hardness(shore- D) 68
Working temperature(℃)-50-130

Remind:The above performance data are typical data measured in the temperature of 25 ℃, humidity of 70% of the laboratory environment, only for reference, we cannot guarantee all the data can achieve under a specific environment. Customers are kindly requested to use actual measure data in using.

Product details

bg
Epoxy resin structural adhesive
SD823 is a high strength acrylate structural adhesive with a two component 10:1 system.
Eco-environmental protection
odorless, non-pollution, safety and environmental protection, medium viscosity, fast curing .
Yellow/blue liquid
It has fast bonding and firmness. hard and tough after curing. high bonding strength and impact resistance, and good resistant to aging and solvent.
AB mixing tube
packaging specifications: 64g /tube

Use instructions

bg


  • Put on AB glue gun and put on the thread mixing head.

  • The thickness of adhesive layer should be 0.05mm, the coated object should be clamped immediately, and the maximum bonding strength will be guaranteed by uniform contact pressure.

  • To obtain the highest mechanical strength, the surface of the material can be polished or sandblasted, and then the dust and oil stains on the surface can be scrubbed with a special solvent.

  • Adhesive should be put on both sides of the object and fix the splice in avoid of dislocation. Do not mix the lid of A and B to prevent contamination of the gum.

Caution

  • 1.   AB adhesive is slightly irritating, please wear gas mask and anticorrosion gloves when operating.

  • 2.   Cover at any time after each extraction, lest moisture absorption affect curing and performance.

  • 3.   Mass use of this product needs to be in a well-ventilated place.


Packaging and preservation

bg


AB glue is packed with AB mixed pipe, 64g/ pcs, transported as non-dangerous goods, should be stored in a dry, shady place (below 5 ℃ ~ 26 ℃), the shelf life is within 12 months from the date of manufacture.


Company Features
1. Huizhou SANDAO New Material Co., Ltd is a global leading epoxy resin company having its own large-scale manufacture base.
2. Huizhou SANDAO New Material Co., Ltd has the most advanced technology and experience in producing 2 part epoxy adhesive in China.
3. Enterprise culture is very important in Huizhou SANDAO New Material Co., Ltd and we highly value it. Inquiry! What is most proud of Huizhou SANDAO New Material Co., Ltd is that we have outstanding epoxy adhesive talents who are working hard to build a 'world-class epoxy ab glue enterprise group'. Inquiry!
Our services

1. Your kind enquiry will be replied in 2 hours or 24 hours if time difference.
2. Competitive prices based on the same quality as we are factory supplier.
3. Samples can be made according to your requirements before placing order.
4. Updating the production schedule regularly.
5. Guarantee samples quality same as the mass production..
6. Specialized team make us strong support to solve your problems from purchase to application.
