◪ High strength, high performance, elastic, instantaneous, two components, safety and environmental protection
suitable for fast fastening and bonding of metal, hard plastics, composite materials, glass, etc., especially for mobile phone and notebook shell, screen and keyboard frame, suitable for high speed production line in electronic factory.
Glass bonding
Hard plastic bonding
Phone case bonding
Composite bonding
Metal bonding
Notebook case bonding
| 1.Before curing | ||
| performance | Component A | Component B |
| color | white | blue |
| specific gravity（25℃） | 1.05 | 1.14 |
| Viscosity (25℃ m pa. s ) | 85000-100000 | 35000-50000 |
| 2.mixed characteristic | ||
| color | Blue | |
| ratio | A:B=10：1 | |
| Applicable time (mins) | 4 | |
| 3.After Curing characteristic | ||
| shear strength（N/mm.2) | PC/Aluminum magnesium | 10.02 |
| shear strength（N/mm.2) | PC/PC | 6.71 |
| Split / elongation % | 150 | |
| Hardness（shore- D) | 68 | |
| Working temperature（℃） | -50-130 | |
Remind:The above performance data are typical data measured in the temperature of 25 ℃, humidity of 70% of the laboratory environment, only for reference, we cannot guarantee all the data can achieve under a specific environment. Customers are kindly requested to use actual measure data in using.
Put on AB glue gun and put on the thread mixing head.
The thickness of adhesive layer should be 0.05mm, the coated object should be clamped immediately, and the maximum bonding strength will be guaranteed by uniform contact pressure.
To obtain the highest mechanical strength, the surface of the material can be polished or sandblasted, and then the dust and oil stains on the surface can be scrubbed with a special solvent.
Adhesive should be put on both sides of the object and fix the splice in avoid of dislocation. Do not mix the lid of A and B to prevent contamination of the gum.
1. AB adhesive is slightly irritating, please wear gas mask and anticorrosion gloves when operating.
2. Cover at any time after each extraction, lest moisture absorption affect curing and performance.
3. Mass use of this product needs to be in a well-ventilated place.
AB glue is packed with AB mixed pipe, 64g/ pcs, transported as non-dangerous goods, should be stored in a dry, shady place (below 5 ℃ ~ 26 ℃), the shelf life is within 12 months from the date of manufacture.
Contract packaging for two component epoxy ab glue epoxy resin adhesive Shin Dorn offers re-packaging services for industrial adhesive glue. Clients provide their own glue product or purchase glue via Shin Dorn. - We fill glue into aluminum collapsible tubes, in sizes ranging from 3 gram to 60 gram. - We fill a variety of glue, such as PVC glue, silicone glue, tire glue, AB glue, rubber cement, neoprene adhesive. - We offer retail packaging services. - We help arrange shipping to your country/area. |
PACKAGING SERVICES | |
    | |
QUICK DETAILS | |
| Services Provided: | Contract packaging for two component epoxy ab glue epoxy resin adhesive |
| Source of Glue: | - Client provides adhesive glue - Client purchases glue via Shin Dorn |
| Glue Types: | Adhesvie glue to be filled should be evaluated and test-filled before an order is placed. Shin Dorn has packaged the following types of adhesive glue: - PVC glue - Silicone glue - Rubber cement/tire glue - AB glue/epoxy glue - Neoprene adhesive |
| Usage: | Glue filled in 3 gram to 60 gram tubes is ideal for household and/or outdoor applications |
| Glue Size: | 3 gram to 60 gram |
| Shelf Life: | Depending on glue type, shelf life is typically 12 months |
| MOQ: | 10,000 pcs For trial orders, 5,000 pcs is acceptable |
| Lead Time: | 30 days |
| Note: | We do not package adhesive glue that contains benzene and other materials not acceptable in US and EU regulations. |
| Company Certificates: | ISO9001:2015 Quality Management System |
FAQ | |
Q: CAN I GET SAMPLES? A: Yes. Free samples are available with freight pre-paid. We use door-to-door shipping. Please contact us for a quote on the freight. If you would like to have CUSTOMIZED samples with your logo printed on them, we can make them for you. You pay for the proofing cost and the air freight. Q: HOW CAN I MAKE A TUBE DESIGN OF MY OWN? A: We will provide you with a template (in PDF file) that shows the dimensions of tube. You can have someone work on the graphic design using software such as Adobe Illustrator ®, and make the layout according to the dimensions. Finally, an AI file with all fonts converted to vector format is what we need for proofing or mass production. Q: WHAT ARE YOUR PAYMENT TERMS? A: T/T (30% deposit in advance, and 70% balance before dispatch), PayPal, L/C at sight for 5,000+ USD, Western Union. Q: WHAT ARE YOUR SHIPPING OPTIONS? A: For adhesive glue, sea freight is fabored. We will provide solutions for logistics according to your requirements. - Door to door shipping. - Air freight to an airport near you. - Ocean freight to a seaport near you. Q: WHAT ARE SHIN DORN’S CORE COMPETENCIES? A: SHIN DORN provides total solutions to fulfill your demands on vinyl repair kits. - SAFE AND STRONG PVC ADHESIVE GLUE: High strength adhesive glue filled in aluminum collapsible tubes. Glue conforms to safety regulations in US and in EU. Test reports are available for clients who have placed orders. - PACKAGING SERVICES: We offer OEM, ODM, private label packaging services. - PARTS ASSEMBLY: Customized repair kits for your demands on design, branding and pricing. - LOGISTICS ARRANGEMENT: Shin Dorn is experienced in delivery of adhesive glue. We will help you arrange logistics. | |
